Wide Oriented PTFE Film

Wide PTFE film formats for laboratory barriers and converted insulating liners, with oriented and skived variants identified separately.

  • Wide barrier formats
  • Oriented and skived options
  • Thin non-adhesive PTFE stock
Request a Quote -> Custom Size ->
Product Overview

Wide Oriented PTFE Film Supplier

The oriented and skived constructions must remain distinct in the order. Their processing history affects handling and direction-dependent behavior. Wider film reduces joins in panels; narrow grades suit winding and strips. Specify construction, thickness and width together when reproducing a laboratory fixture or insulation part.

Technical Specifications

Product Parameters

Material and construction Oriented and skived PTFE film
Standard formats 0.1 mm × 1 m × 1 m Skived; 0.03 mm × 200 mm × 5 m Oriented; 0.03 mm × 300 mm × 5 m Oriented; 28 listed formats
Ordering model HT-052
Price Request a Quote
Construction options Wide barrier formats; Oriented and skived options; Thin non-adhesive PTFE stock
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-052-002 0.1 mm × 1 m × 1 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-003 0.03 mm × 200 mm × 5 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-004 0.03 mm × 300 mm × 5 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-005 0.05 mm × 200 mm × 5 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-006 0.05 mm × 300 mm × 5 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-007 0.05 mm × 300 mm × 5 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-008 0.08 mm × 300 mm × 5 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-009 0.03 mm × 200 mm × 10 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-010 0.03 mm × 300 mm × 10 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-011 0.05 mm × 200 mm × 10 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-012 0.05 mm × 300 mm × 10 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-013 0.05 mm × 300 mm × 10 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-014 0.08 mm × 300 mm × 10 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-015 0.1 mm × 300 mm × 10 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-016 0.1 mm × 300 mm × 10 m Oriented Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-017 0.3 mm × 200 mm × 10 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-018 0.3 mm × 200 mm × 5 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-019 0.1 mm × 300 mm × 5 m Skived film; Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-020 0.03 mm × 300 mm × 5 m Skived film; Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-021 0.03 mm × 300 mm × 10 m Skived film; Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-022 0.08 mm × 300 mm × 5 m Skived film; Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-023 0.08 mm × 300 mm × 10 m Skived film; Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-024 0.2 mm × 200 mm × 5 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-025 0.5 mm × 200 mm × 5 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-026 0.5 mm × 1 m × 1 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-027 0.5 mm × 300 mm × 5 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-028 0.2 mm × 300 mm × 1 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote
HT-052-029 0.2 mm × 300 mm × 5 m Skived Oriented and skived PTFE film Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Laboratory separator panels
  • Electrical winding barriers
  • Converted release liners
Customization Options

Wide Oriented PTFE Film Ordering Options

Send Requirement ->

For Wide Oriented PTFE Film, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material Oriented and skived PTFE film
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which wide and narrow formats are listed for oriented PTFE film?

The table includes 1 m × 1 m skived sheets and selected 200 or 300 mm-wide formats in 5 or 10 m lengths. Thicknesses and lengths differ between the oriented and skived entries, so select the full construction-and-size description.

Are oriented and skived PTFE film separate options?

Yes. The table explicitly marks oriented and skived entries. The construction options describe thin non-adhesive PTFE stock; adhesive backing is not identified for these formats.

What material is used for Wide Oriented PTFE Film?

The specified material is oriented and skived PTFE film.

What should I include in a quotation request?

For model HT-052, send the selected SKU and order quantity. Include oriented or skived construction, thickness, width and length. Pricing is by quotation for the selected specification and quantity.
