Unlaminated Adhesive Fish Paper

Unlaminated green adhesive fish paper in 0.15–0.5 mm formats for positioned electrical barriers and die-cut insulating pads.

  • Unlaminated cellulose face
  • Single adhesive backing
  • 1 m-wide listed formats
Request a Quote -> Custom Size ->
Product Overview

Unlaminated Adhesive Fish Paper Supplier

A self-adhesive backing holds the cellulose barrier in place while the assembly is built. This construction keeps the paper face unlaminated, distinguishing it from film-faced stock. Plan overlap around metal edges and avoid stretching the liner while peeling it from the release paper.

Technical Specifications

Product Parameters

Material and construction Cellulose electrical fish paper with adhesive backing
Standard formats Unlaminated, adhesive-backed; 0.15 mm × 1 m width; Unlaminated, adhesive-backed; 0.2 mm × 1 m width; Unlaminated, adhesive-backed; 0.25 mm × 1 m width; 6 listed formats
Ordering model HT-021
Price Request a Quote
Construction options Unlaminated cellulose face; Single adhesive backing; 1 m-wide listed formats
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-021-P001 Unlaminated, adhesive-backed; 0.15 mm × 1 m width Cellulose electrical fish paper with adhesive backing Roll / cut length Request a Quote
HT-021-P002 Unlaminated, adhesive-backed; 0.2 mm × 1 m width Cellulose electrical fish paper with adhesive backing Roll / cut length Request a Quote
HT-021-P003 Unlaminated, adhesive-backed; 0.25 mm × 1 m width Cellulose electrical fish paper with adhesive backing Roll / cut length Request a Quote
HT-021-P004 Unlaminated, adhesive-backed; 0.3 mm × 1 m width Cellulose electrical fish paper with adhesive backing Roll / cut length Request a Quote
HT-021-P005 Unlaminated, adhesive-backed; 0.4 mm × 1 m width Cellulose electrical fish paper with adhesive backing Roll / cut length Request a Quote
HT-021-P006 Unlaminated, adhesive-backed; 0.5 mm × 1 m width Cellulose electrical fish paper with adhesive backing Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Battery enclosure barriers
  • Motor insulating pads
  • Die-cut assembly liners
Customization Options

Unlaminated Adhesive Fish Paper Ordering Options

Send Requirement ->

For Unlaminated Adhesive Fish Paper, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material Cellulose electrical fish paper with adhesive backing
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which thicknesses are listed for unlaminated adhesive fish paper?

The six listed thicknesses are 0.15, 0.2, 0.25, 0.3, 0.4 and 0.5 mm. Each entry is 1 m wide and is explicitly identified as unlaminated and adhesive-backed.

Does unlaminated mean this fish paper has no adhesive?

No. The specified face is unlaminated cellulose paper, while the backing is adhesive. These entries have a single adhesive backing; a film-laminated face is not the construction listed for this product.

What material is used for Unlaminated Adhesive Fish Paper?

The specified material is cellulose electrical fish paper with adhesive backing.

What should I include in a quotation request?

For model HT-021, send the selected SKU and order quantity. Include paper thickness, 1 m reference width, required length and adhesive-backed construction. Pricing is by quotation for the selected specification and quantity.
