PTFE Film Adhesive Tape

PTFE film adhesive tape in 0.08 mm listed thickness and 13–300 mm widths for smooth low-friction contact surfaces.

  • Smooth film backing
  • 0.08 mm listed thickness
  • Narrow guide and wide-face formats
Request a Quote -> Custom Size ->
Product Overview

PTFE Film Adhesive Tape Supplier

A film backing gives a different contact texture from woven fiberglass tape. The narrow sizes line small guides, while broad formats cover larger faces. Select the contact width and expected wear path, then apply to a clean smooth substrate so folds do not create raised edges in the sliding area.

Technical Specifications

Product Parameters

Material and construction PTFE film with pressure-sensitive adhesive
Standard formats 0.08 mm thickness × 13 mm width × 10 m length; 0.08 mm thickness × 19 mm width × 10 m length; 0.08 mm thickness × 25 mm width × 10 m length; 14 listed formats
Ordering model HT-061
Price Request a Quote
Construction options Smooth film backing; 0.08 mm listed thickness; Narrow guide and wide-face formats
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-061-001 0.08 mm thickness × 13 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-002 0.08 mm thickness × 19 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-003 0.08 mm thickness × 25 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-004 0.08 mm thickness × 38 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-005 0.08 mm thickness × 50 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-006 0.08 mm thickness × 55 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-007 0.08 mm thickness × 60 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-008 0.08 mm thickness × 70 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-009 0.08 mm thickness × 80 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-010 0.08 mm thickness × 90 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-011 0.08 mm thickness × 100 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-012 0.08 mm thickness × 120 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-013 0.08 mm thickness × 150 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote
HT-061-014 0.08 mm thickness × 300 mm width × 10 m length PTFE film with pressure-sensitive adhesive Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Sliding guide liners
  • Non-stick machine faces
  • Release strips on fixtures
Customization Options

PTFE Film Adhesive Tape Ordering Options

Send Requirement ->

For PTFE Film Adhesive Tape, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material PTFE film with pressure-sensitive adhesive
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which dimensions are listed for PTFE film adhesive tape?

All 14 entries specify 0.08 mm thickness and 10 m roll length. Listed widths include 13, 19, 25, 38, 50, 55, 60, 70, 80, 90, 100, 120, 150 and 300 mm.

Is this tape backed with PTFE film or woven fiberglass?

The specified construction is PTFE film with pressure-sensitive adhesive and a smooth film backing. Woven fiberglass reinforcement is not named for these tape entries.

What material is used for PTFE Film Adhesive Tape?

The specified material is PTFE film with pressure-sensitive adhesive.

What should I include in a quotation request?

For model HT-061, send the selected SKU and order quantity. Include selected tape width, 0.08 mm thickness, 10 m roll length and number of rolls. Pricing is by quotation for the selected specification and quantity.
