PTFE Film Rolls for Precision Conversion

PTFE film rolls in narrow and wide formats for precision cutting, electrical separation and low-friction release layers.

  • Broad roll-width selection
  • Thin converted film formats
  • Separate construction variants
Request a Quote -> Custom Size ->
Product Overview

PTFE Film Rolls for Precision Conversion Supplier

This roll range supports repeated conversion where thickness and web width determine the cutting layout. Select skived or oriented construction explicitly. Use the finished blank dimensions to calculate web yield, and support thin film during cutting so the part is not distorted while being removed from the roll.

Technical Specifications

Product Parameters

Material and construction PTFE fluoropolymer film
Standard formats 0.1 mm × 1 m × 1 m; Skived film; 0.03 mm × 120 mm × 5 m; Skived film; 0.1 mm × 300 mm × 2 m; 76 listed formats
Ordering model HT-053
Price Request a Quote
Construction options Broad roll-width selection; Thin converted film formats; Separate construction variants
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-053-002 0.1 mm × 1 m × 1 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-003 Skived film; 0.03 mm × 120 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-004 Skived film; 0.1 mm × 300 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-005 0.03 mm × 14 mm width × 1 KG approximately 1035 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-006 0.5 mm × 100 mm × 1 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-007 0.03 mm × 90 mm × 1 KG approximately 161 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-008 0.03 mm × 100 mm × 1 KG approximately 145 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-009 0.04 mm × 90 mm × 1 KG approximately 121 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-010 0.04 mm × 100 mm × 1 KG approximately 109 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-011 0.05 mm × 90 mm × 1 KG approximately 97 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-012 0.05 mm × 5 mm × 1 KG PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-013 0.05 mm × 100 mm × 1 KG approximately 87 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-014 0.07 mm × 7 mm × 1 KG PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-015 0.07 mm × 35 mm × 1 KG approximately 177 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-016 0.1mmx12 mm width × 1 KG approximately 362 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-017 0.1 mm × 35 mm × 1 KG approximately 124 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-018 0.1 mm × 45 mm × 1 KG approximately 97 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-019 0.1 mm × 100 mm × 1 KG approximately 43 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-020 0.2 mm × 100 mm × 1 KG approximately 22 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-021 0.3 mm × 100 mm × 1 KG approximately 14 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-022 0.5 mm × 100 mm × 1 KG approximately 9 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-023 0.05 mm × 15 mm width × 1 kg approximately 580 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-024 0.1 mm × 30 mm × 1 kg approximately 145 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-025 Oriented film; 0.03 mm × 300 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-026 Skived film; 0.03 mm × 300 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-027 0.03 mm × 100 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-028 0.04 mm × 90 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-029 0.04 mm × 100 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-030 0.1 mm × 100 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-031 0.05 mm × 100 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-032 Oriented film; 0.05 mm × 300 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-033 0.3 mm × 200 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-034 Skived film; 0.05 mm × 300 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-035 0.08 mm × 100 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-036 0.2 mm × 100 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-037 Oriented film; 0.1 mm × 300 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-038 0.3 mm × 100 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-039 Skived film; 0.03 mm × 100 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-040 0.03 mm × 90 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-041 0.07 mm × 35 mm × 10 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-042 Oriented film; 0.2 mm × 210 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-043 Oriented film; 0.2 mm × 210 mm × 1 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-044 Oriented film; 0.2 mm × 210 mm × 10 m(1 KG) PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-045 Skived film; 0.08 mm × 300 mm × 2 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-046 0.03 mm × 200 mm × 5 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-047 0.03 mm × 300 mm × 5 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-048 0.05 mm × 200 mm × 5 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-049 0.05 mm × 300 mm × 5 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-050 0.05 mm × 300 mm × 5 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-051 0.08 mm × 300 mm × 5 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-052 0.03 mm × 200 mm × 10 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-053 0.03 mm × 300 mm × 10 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-054 0.05 mm × 200 mm × 10 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-055 0.05 mm × 300 mm × 10 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-056 0.05 mm × 300 mm × 10 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-057 0.08 mm × 300 mm × 10 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-058 0.1 mm × 300 mm × 10 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-059 0.1 mm × 300 mm × 10 m Oriented PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-060 0.3 mm × 200 mm × 10 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-061 0.3 mm × 200 mm × 5 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-062 0.3 mm × 300 mm × 1 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-063 0.3 mm × 300 mm × 5 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-064 0.5 mm × 300 mm × 1 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-065 0.1 mm × 200 mm × 10 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-066 0.1 mm × 200 mm × 5 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-067 0.3 mm × 50 mm × 5 m PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-068 0.03 mm × 300 mm × 5 m Skived film; PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-069 0.03 mm × 300 mm × 10 m Skived film; PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-070 0.08 mm × 300 mm × 5 m Skived film; PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-071 0.08 mm × 300 mm × 10 m Skived film; PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-072 0.2 mm × 200 mm × 5 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-073 0.5 mm × 200 mm × 5 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-074 0.5 mm × 1 m × 1 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-075 0.5 mm × 300 mm × 5 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-076 0.2 mm × 300 mm × 5 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote
HT-053-077 0.2 mm × 300 mm × 1 m Skived PTFE fluoropolymer film Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Precision insulating strips
  • Laboratory release layers
  • Low-friction film blanks
Customization Options

PTFE Film Rolls for Precision Conversion Ordering Options

Send Requirement ->

For PTFE Film Rolls for Precision Conversion, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material PTFE fluoropolymer film
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

How are length-based and kilogram-based PTFE film formats listed?

The table includes fixed-length formats and separate 1 kg entries. Some weight-based entries give approximate lengths, such as 0.03 mm × 100 mm × 1 kg at approximately 145 m. Treat an approximate length as part of that entry, not as a guaranteed length for every roll.

Are oriented and skived versions included in the conversion-film table?

Yes. Separate entries explicitly identify oriented film or skived film. Other entries state dimensions without naming either construction; confirm the construction if it is required for the selected format.

What material is used for PTFE Film Rolls for Precision Conversion?

The specified material is PTFE fluoropolymer film.

What should I include in a quotation request?

For model HT-053, send the selected SKU and order quantity. Include film construction, thickness, width and selected length or kilogram basis. Pricing is by quotation for the selected specification and quantity.
