Nylon Toothed Drive Belts for Band Sealers

Nylon toothed drive belts in 410–660 mm listed circumferences for packaging sealer drive and feed assemblies.

  • Toothed nylon construction
  • Six listed loop lengths
  • Five- and ten-belt packs
Request a Quote -> Custom Size ->
Product Overview

Nylon Toothed Drive Belts for Band Sealers Supplier

The teeth engage a matching drive profile rather than relying on a smooth friction face. Circumference is only one fit dimension: tooth pitch, belt width and pulley geometry must also match. Replace worn belts as a drive component and check pulley condition before installing a new loop.

Technical Specifications

Product Parameters

Material and construction Nylon toothed belt
Standard formats Toothed belt; Circumference 410 mm 10 pieces; Toothed belt; Circumference 420 mm 10 pieces; Toothed belt; Circumference 428 mm 10 pieces; 12 listed formats
Ordering model HT-027
Price Request a Quote
Construction options Toothed nylon construction; Six listed loop lengths; Five- and ten-belt packs
MOQ Quoted by the selected supply unit and quantity
Packaging Coils or matched sets protected against sharp bends and packed in cartons.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-027-P001 Toothed belt; Circumference 410 mm 10 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P002 Toothed belt; Circumference 420 mm 10 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P003 Toothed belt; Circumference 428 mm 10 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P004 Toothed belt; Circumference 600 mm 10 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P005 Toothed belt; Circumference 630 mm 10 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P006 Toothed belt; Circumference 660 mm 10 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P007 Toothed belt; Circumference 410 mm 5 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P008 Toothed belt; Circumference 420 mm 5 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P009 Toothed belt; Circumference 428 mm 5 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P010 Toothed belt; Circumference 600 mm 5 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P011 Toothed belt; Circumference 630 mm 5 pieces Nylon toothed belt Listed pack Request a Quote
HT-027-P012 Toothed belt; Circumference 660 mm 5 pieces Nylon toothed belt Listed pack Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Band sealer drive maintenance
  • Packaging feed assemblies
  • Small conveyor drives
Customization Options

Nylon Toothed Drive Belts for Band Sealers Ordering Options

Send Requirement ->

For Nylon Toothed Drive Belts for Band Sealers, specify width, circumference, joint and machine layout.

  • Dimensions and construction Specify width, circumference, joint and machine layout.
  • Material Nylon toothed belt
  • Supply and packing Coils or matched sets protected against sharp bends and packed in cartons.
FAQ

Frequently Asked Questions

Which loop lengths are listed for nylon toothed drive belts?

The six circumferences are 410, 420, 428, 600, 630 and 660 mm. Each is listed in a five-piece and a ten-piece pack. The table identifies nylon toothed belts, rather than PTFE sealing belts.

Are belt width and tooth pitch specified in the listed drive-belt entries?

The table states circumference and pack quantity but does not give belt width or tooth pitch. Include those dimensions or a matching belt drawing so the selected loop can be reviewed for your machine.

What material is used for Nylon Toothed Drive Belts for Band Sealers?

The specified material is nylon toothed belt.

What should I include in a quotation request?

For model HT-027, send the selected SKU and order quantity. Include circumference, belt width, tooth pitch and five-piece or ten-piece pack. Pricing is by quotation for the selected specification and quantity.
