Laminated Adhesive Green Fish Paper

Laminated adhesive green fish paper for positioned battery liners, motor barriers and converted insulating pieces.

  • Laminated paper face
  • Single adhesive backing
  • Six listed thickness formats
Request a Quote -> Custom Size ->
Product Overview

Laminated Adhesive Green Fish Paper Supplier

This construction combines a film-faced paper barrier with adhesive positioning. It differs from unlaminated adhesive stock even when the thickness appears similar. Include the finished thickness and face arrangement in a die-cut drawing, then keep the release backing on until the part is ready to fit.

Technical Specifications

Product Parameters

Material and construction Film-laminated cellulose fish paper with adhesive
Standard formats Laminated, adhesive-backed; 0.15 mm; Laminated, adhesive-backed; 0.2 mm × 1 m; Laminated, adhesive-backed; 0.25 mm × 1 m; 6 listed formats
Ordering model HT-076
Price Request a Quote
Construction options Laminated paper face; Single adhesive backing; Six listed thickness formats
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-076-P001 Laminated, adhesive-backed; 0.15 mm Film-laminated cellulose fish paper with adhesive Roll / cut length Request a Quote
HT-076-P002 Laminated, adhesive-backed; 0.2 mm × 1 m Film-laminated cellulose fish paper with adhesive Roll / cut length Request a Quote
HT-076-P003 Laminated, adhesive-backed; 0.25 mm × 1 m Film-laminated cellulose fish paper with adhesive Roll / cut length Request a Quote
HT-076-P004 Laminated, adhesive-backed; 0.32 mm Film-laminated cellulose fish paper with adhesive Roll / cut length Request a Quote
HT-076-P005 Laminated, adhesive-backed; 0.42 mm Film-laminated cellulose fish paper with adhesive Roll / cut length Request a Quote
HT-076-P006 Laminated, adhesive-backed; 0.52 mm Film-laminated cellulose fish paper with adhesive Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Battery liner positioning
  • Motor barrier conversion
  • Die-cut insulating parts
Customization Options

Laminated Adhesive Green Fish Paper Ordering Options

Send Requirement ->

For Laminated Adhesive Green Fish Paper, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material Film-laminated cellulose fish paper with adhesive
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which thicknesses are listed for laminated adhesive green fish paper?

The six listed gauges are 0.15, 0.2, 0.25, 0.32, 0.42 and 0.52 mm. The 0.2 and 0.25 mm entries specify 1 m width; other entries give thickness only, so confirm the required width with the selected SKU.

Does this green paper include both film lamination and adhesive?

Yes. The material description specifies film-laminated cellulose fish paper with adhesive, and the construction options identify a laminated paper face and single adhesive backing.

What material is used for Laminated Adhesive Green Fish Paper?

The specified material is film-laminated cellulose fish paper with adhesive.

What should I include in a quotation request?

For model HT-076, send the selected SKU and order quantity. Include laminated adhesive construction, thickness, confirmed width and required length. Pricing is by quotation for the selected specification and quantity.
