Brass Woven Filter and Screening Mesh

Brass woven mesh in multiple counts for strainers, screening panels and conductive inserts.

  • Brass woven construction
  • Heavy-wire variants
  • Coarse and fine screening grades
Request a Quote -> Custom Size ->
Product Overview

Brass Woven Filter and Screening Mesh Supplier

The yellow copper-alloy weave combines screening openings with a conductive wire network. Fine formats require appropriate support; heavier-wire grades offer a different opening at the same count. Specify the wire diameter and exposure environment when converting the mesh into a fitted panel or strainer.

Technical Specifications

Product Parameters

Material and construction Brass wire
Standard formats 500 mesh; 450 mesh; 400 mesh; 25 listed formats
Ordering model HT-069
Price Request a Quote
Construction options Brass woven construction; Heavy-wire variants; Coarse and fine screening grades
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-069-P001 500 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P002 450 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P003 400 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P004 350 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P005 325 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P006 300 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P007 280 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P008 250 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P009 220 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P010 200 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P011 180 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P012 150 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P013 120 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P014 100 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P015 80 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P016 60 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P017 40 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P018 30 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P019 24 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P020 20 mesh Brass wire Roll / cut panel Request a Quote
HT-069-P021 20 mesh, extra-heavy wire Brass wire Roll / cut panel Request a Quote
HT-069-P022 12 mesh, extra-heavy wire Brass wire Roll / cut panel Request a Quote
HT-069-P023 10 mesh, extra-heavy wire Brass wire Roll / cut panel Request a Quote
HT-069-P024 30 mesh, heavy wire Wire diameter 0.15 mm Brass wire Roll / cut panel Request a Quote
HT-069-P025 40 mesh, heavy wire Wire diameter 0.15 mm Brass wire Roll / cut panel Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Industrial strainer inserts
  • Conductive screening panels
  • Fine material separation
Customization Options

Brass Woven Filter and Screening Mesh Ordering Options

Send Requirement ->

For Brass Woven Filter and Screening Mesh, specify mesh count or opening, wire or yarn diameter, panel dimensions and edge finish.

  • Dimensions and construction Specify mesh count or opening, wire or yarn diameter, panel dimensions and edge finish.
  • Material Brass wire
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which counts are listed for brass woven mesh?

The table includes fine counts such as 500, 450 and 400 mesh, plus lower-count entries and separately labelled heavy-wire or extra-heavy-wire versions. Select the full count-and-wire-description entry.

Are wire diameters given for all brass mesh entries?

No. The 30-mesh and 40-mesh heavy-wire entries explicitly state 0.15 mm wire diameter, but many other entries do not state a diameter. Include any required wire diameter or opening size for confirmation.

What material is used for Brass Woven Filter and Screening Mesh?

The specified material is brass wire.

What should I include in a quotation request?

For model HT-069, send the selected SKU and order quantity. Include brass mesh count, wire description, roll or panel dimensions and any aperture requirement. Pricing is by quotation for the selected specification and quantity.
