316L Stainless Steel Corrosion Resistant Mesh

316L woven wire mesh in 18–600 mesh grades for process strainers, chemical filtration and laboratory screens.

  • Low-carbon 316L alloy
  • 18–600 mesh catalogue grades
  • Roll and cut-panel sourcing
Request a Quote -> Custom Size ->
Product Overview

316L Stainless Steel Corrosion Resistant Mesh Supplier

The low-carbon molybdenum-bearing stainless alloy suits filtration equipment exposed to demanding liquids. A fine mesh captures smaller particles but increases resistance to flow. Aperture, wire diameter and unsupported span belong in the specification alongside the selected mesh count.

Technical Specifications

Product Parameters

Material and construction 316L stainless steel wire
Standard formats 600 mesh; 500 mesh; 450 mesh; 23 listed formats
Ordering model HT-003
Price Request a Quote
Construction options Low-carbon 316L alloy; 18–600 mesh catalogue grades; Roll and cut-panel sourcing
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-003-P001 600 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P002 500 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P003 450 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P004 400 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P005 380 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P006 350 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P007 325 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P008 300 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P009 280 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P010 250 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P011 220 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P012 200 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P013 180 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P014 150 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P015 120 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P016 100 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P017 80 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P018 60 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P019 50 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P020 40 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P021 30 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P022 20 mesh 316L stainless steel wire Roll / cut panel Request a Quote
HT-003-P023 18 mesh 316L stainless steel wire Roll / cut panel Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Chemical process strainers
  • Laboratory filtration assemblies
  • Corrosion-exposed screening
Customization Options

316L Stainless Steel Corrosion Resistant Mesh Ordering Options

Send Requirement ->

For 316L Stainless Steel Corrosion Resistant Mesh, specify mesh count or opening, wire or yarn diameter, panel dimensions and edge finish.

  • Dimensions and construction Specify mesh count or opening, wire or yarn diameter, panel dimensions and edge finish.
  • Material 316L stainless steel wire
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which counts are listed for the 316L woven mesh?

There are 23 listed mesh counts from 18 to 600 mesh. Examples include 20, 60, 100, 200, 325, 450 and 500 mesh. Use the table to select the required count rather than treating the range as a continuous set of sizes.

Can the 316L mesh be quoted as rolls or cut panels?

The supply format is listed as roll / cut panel. The mesh count alone does not define the roll width or panel outline; include the required dimensions when selecting a SKU.

What material is used for 316L Stainless Steel Corrosion Resistant Mesh?

The specified material is 316L stainless steel wire.

What should I include in a quotation request?

For model HT-003, send the selected SKU and order quantity. Include mesh count, roll width or cut-panel dimensions and any required wire or aperture dimensions. Pricing is by quotation for the selected specification and quantity.
