FEP Spiral Cable Wrap

Clear FEP spiral wrap in paired diameter sizes for accessible bundling of cables and small process lines.

  • Spiral-cut openable construction
  • Transparent bundle visibility
  • 1 m listed lengths
Request a Quote -> Custom Size ->
Product Overview

FEP Spiral Cable Wrap Supplier

The spiral cut lets the wrap open around an existing bundle without threading every connector through a sleeve. It also permits branch wires to exit between turns. Choose a diameter that fits the bundle without excessive stretch and keep enough overlap to maintain coverage at bends.

Technical Specifications

Product Parameters

Material and construction FEP fluoropolymer spiral-cut tube
Standard formats FEP Clear 2.6 × 3.6 mm(1 m ); FEP Clear 3 × 5 mm(1 m ); FEP Clear 4 × 6 mm(1 m ); 8 listed formats
Ordering model HT-051
Price Request a Quote
Construction options Spiral-cut openable construction; Transparent bundle visibility; 1 m listed lengths
MOQ Quoted by the selected supply unit and quantity
Packaging Coils or matched sets protected against sharp bends and packed in cartons.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-051-001 FEP Clear 2.6 × 3.6 mm(1 m ) FEP fluoropolymer spiral-cut tube Roll / cut length Request a Quote
HT-051-002 FEP Clear 3 × 5 mm(1 m ) FEP fluoropolymer spiral-cut tube Roll / cut length Request a Quote
HT-051-003 FEP Clear 4 × 6 mm(1 m ) FEP fluoropolymer spiral-cut tube Roll / cut length Request a Quote
HT-051-004 FEP Clear 6 × 8 mm(1 m ) FEP fluoropolymer spiral-cut tube Roll / cut length Request a Quote
HT-051-005 FEP Clear 8 × 10 mm(1 m ) FEP fluoropolymer spiral-cut tube Roll / cut length Request a Quote
HT-051-006 FEP Clear 10 × 12 mm(1 m ) FEP fluoropolymer spiral-cut tube Roll / cut length Request a Quote
HT-051-007 FEP Clear 14 × 16 mm(1 m ) FEP fluoropolymer spiral-cut tube Roll / cut length Request a Quote
HT-051-008 FEP Clear 16 × 18 mm(1 m ) FEP fluoropolymer spiral-cut tube Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Equipment cable bundling
  • Laboratory line routing
  • Accessible harness protection
Customization Options

FEP Spiral Cable Wrap Ordering Options

Send Requirement ->

For FEP Spiral Cable Wrap, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material FEP fluoropolymer spiral-cut tube
  • Supply and packing Coils or matched sets protected against sharp bends and packed in cartons.
FAQ

Frequently Asked Questions

Which sizes and lengths are listed for FEP spiral cable wrap?

The listed dimension pairs are 2.6 × 3.6, 3 × 5, 4 × 6, 6 × 8, 8 × 10, 10 × 12, 14 × 16 and 16 × 18 mm. Each entry specifies a 1 m length and clear FEP.

Is FEP spiral wrap supplied as a closed uncut tube?

The construction is described as spiral-cut and openable, with transparent bundle visibility. It is not described as an uncut closed tube; retain the spiral-wrap construction and listed dimension pair in the inquiry.

What material is used for FEP Spiral Cable Wrap?

The specified material is FEP fluoropolymer spiral-cut tube.

What should I include in a quotation request?

For model HT-051, send the selected SKU and order quantity. Include listed dimension pair, 1 m reference length and number of pieces. Pricing is by quotation for the selected specification and quantity.
